Specility:
1) Anti-fractured PET organic synthetic fibre;
2) Large dust holding capacity, small resistance, long service life and economical;
3) Contain no silicons other lacquer harming substances
4) The windward side is blue/yellow/green, the leeward side is white
5) Conform to European and American classfications for nonflammability( e. G DIN53438-F1, UL900-class 2 with flameout);
6) Available in paper frame, galvanize frame, aluminium frame and so on.
1) Anti-fractured PET organic synthetic fibre;
2) Large dust holding capacity, small resistance, long service life and economical;
3) Contain no silicons other lacquer harming substances
4) The windward side is blue/yellow/green, the leeward side is white
5) Conform to European and American classfications for nonflammability( e. G DIN53438-F1, UL900-class 2 with flameout);
6) Available in paper frame, galvanize frame, aluminium frame and so on.
| model | C16-300 |
| thickness | 15mm |
| air velocity | 1.5 m /S |
| initial efficiency(%) | < 20 |
| Initial resistance | 25Pa |
| Final resistance | 250Pa |
| Avg. arrestance(acc. EN779) | 88% |
| Temp. resistance | 100 deg C |
| Temp. short peaks | 120 deg C |
| Dust holding at tested final | 600 g/m2 |
| Filtration class | G4 |
| Normal size | 1*20 2*20 |
